Furukawa Electric Achieves World’s First Installation of World’s Highest Density 6912 Fiber Optic Cable into 1.25 inch Diameter Conduit

- Enables Expansion in Data Centers using Existing Duct -

August 3, 2020

World’s highest density 6912 fiber optic cable into 1.25 inch diameter conduit
To increase data center capacity with ultra-high fiber count cable in existing small conduit
To support data center contractor for providing necessary tools and instruction training

Content

The continuing rapid increase in bandwidth demand has created an urgent need for data centers to increase the capacity of optical fiber networks. Within and between existing data center buildings, it has become necessary to maximize the fiber count in existing conduit to avoid expensive and time-consuming creation of new installations.

Furukawa Electric Co., Ltd. (FEC) conducted an experiment in its Mie, Japan facility to demonstrate the installation of a 6912-fiber optic cable with an outer diameter of 1.14 inches (29 mm) in a 696 feet (200m) long conduit with three 90 degree curves and an inner diameter of 1.25 inches (32mm). The conduit used was a standard product installed in conventional data center campuses. Engineers confirmed a maximum pulling tension of 84 pounds (372N), well below the maximum pulling tension of 600 pounds (2700N) specified for the cable.

6912 fiber optic cable

6912 fiber optic cable through a conduit with
an inner diameter of 1.25 inches

The cable was installed in a 1.25 inch (32mm) conduit with a maximum length of 1,411 feet (430m) in a North American data center campus in 2020 to support live traffic. The high fill ratio in this application is not typically recommended for Outside Plant (OSP) cable installation. However, in this application, the end-user was willing to accept the installation risk in return for maximum fiber density. The installation demonstrated that FEC’s 6912 fiber optic cable can be successfully installed into 1.25 inch (32mm) conduit using appropriate tools, work procedures, and optimum installation conditions.

“The FEC 6912 fiber optic cable at least doubled the fiber count possible in a 1.25 inch conduit, compared to competing available designs,” said Ichiro Kobayashi, General Manager of optical fiber & cable engineering department, FEC.

FEC will continue to provide and improve its ultra-high fiber count cabling, featuring small diameter and high density, along with the tools and training necessary to successfully build high capacity networks.
